36 DCD Exploded View
| No | Part No | Description | Qty |
|---|---|---|---|
| 1 | Not Available | Carburetor Top Cover | 1 |
| 2 | 64700.001 | Carburetor Cover Fixing Screw | 6 |
| 3 | 10140.010 | Lock Washer | 1 |
| 4 | 12775.013 | Starter Plunger Seat | 1 |
| 5 | 58600.007 | Starter Plunger | 1 |
| 6 | 47600.052 | Starter Plunger Spring | 1 |
| 7 | 61002.010 | Filter Cover | 1 |
| 8 | 41530.024 | Filter Cover Gasket | 1 |
| 9 | 37022.010 | Gauze Filter | 1 |
| 10 | 41705.002 | Top Cover Gasket | 1 |
| 11 | 83102.070 | Float Pin | 1 |
| 12 | 83102.070 | Needle Valve Gasket | 1 |
| 13 | 10400.012 | Plunger Shaft | 1 |
| 14 | 52140.002 | Plunger Spring Retaining Plate | 1 |
| 15 | 47600.085 | Pump Plunger Spring | 1 |
| 16 | 79507.* | Needle & Seat | 1 |
| 17 | 41030.011 | Float | 1 |
| 18 | 77505.* | Air Corrector Jet | 1 |
| 19 | 75504.* | Starter Jet | 1 |
| 20 | 58602.004 | Pump Plunger | 1 |
| 21 | 79701.* | Intake Valve With Exhaust Orifice | 1 |
| 22 | 74401.* | Idle Jet | 1 |
| 23 | 41565.045 | Idle Jet Holder Gasket | 1 |
| 24 | 52570.005 | Idle Jet Holder | 1 |
| 25 | 41540.001 | Main Jet Holder Gasket | 2 |
| 26 | 73801.* | Primary Main Jet | 1 |
| 26a | 73801.* | Secondary Main Jet | 1 |
| 27 | 52590.001 | Main Jet Holder | 2 |
| 28 | 61015.001 | Inspection Screw | 1 |
| 29 | 64625.002 | Throttle Adjustment Screw | 1 |
| 30 | 47600.084 | Idle Mixture Screw Spring | 1 |
| 30a | 47600.084 | Throttle Adjustment Screw Spring | 1 |
| 31 | 64755.006 | Idle Mixture Adjustment Screw | 1 |
| 32 | Not Available | Split Pin | 2 |
| 33 | 12775.012 | Shaft Nut | 1 |
| 34 | 45080.010 | Second Pumping Lever | 1 |
| 35 | 45067.001 | Pump Control Loosened Lever | 1 |
| 36 | 34720.001 | Shaft Nut | 2 |
| 37 | 45080.011 | Pumping Lever | 1 |
| 38 | Not Available | Carburetor Body | 1 |
| 39 | Not Available | Spindle Grommet | 4 |
| 40 | 64005.046 | Throttle Valve For Secondary Duct | 1 |
| 41 | 10015.407 | Shaft For Secondary Duct | 1 |
| 42 | 10015.416 | Shaft For Primary Duct | 1 |
| 43 | Not Available | Throttle Valve Fixing Screw | 4 |
| 44 | 64005.045 | Throttle Valve For Primary Duct | 1 |
| 45 | 47610.034 | Return Spring | 1 |
| 46 | 12750.039 | Shaft Distance Piece | 1 |
| 47 | 55555.016 | Primary Shaft Distance Washer | 1 |
| 48 | 47610.009 | Return Spring- Primary Toothed Sector | 1 |
| 49 | 58202.001 | Primary Toothed Sector | 1 |
| 50 | 32464.008 | Toothed Sector Box Cover | 1 |
| 51 | 45027.001 | Throttle Control Lever | 1 |
| 52 | 55520.002 | Tab Washer | 1 |
| 53 | 34715.014 | Throttle Control Lever Fixing Nut | 1 |
| 54 | 64570.004 | Screw, Toothed Sector Cover Box | 2 |
| 55 | 64700.004 | Fixing Screw, Sheath Support Cover | 4 |
| 56 | 32536.005 | Sheath Support Cover | 1 |
| 57 | 45027.017 | Starter Control Lever | 1 |
| 58 | 64800.002 | Cable Fixing Screw | 1 |
| 59 | 45025.003 | Starter Control Lever | 1 |
| 60 | 34720.002 | Cable Fixing Screw Nut | 1 |
| 61 | 34715.010 | Starter Control Lever Fixing Nut | 1 |
| 62 | 47610.004 | Starter Control Lever Return Spring | 1 |
| 63 | 64605.017 | Sheath Fixing Screw | 1 |
| 64 | Not Available | Cover With Sheath Support | 1 |
| 65 | 10085.004 | Starter Valve Control Shaft | 1 |
| 66 | 52030.001 | Spring Guide And Retainer | 1 |
| 67 | 47600.051 | Starter Valve Spring | 1 |
| 68 | 64330.001 | Starter Valve | 1 |
| 69 | 41540.014 | Pump Jet Gasket | 2 |
| 70 | 76203.* | Pump Jet | 1 |
| 71 | 64290.005 | Pump Delivery Valve | 1 |
| 72 | 71702.* | Primary Venturi | 1 |
| 72a | 71701.* | Secondary Venturi | 1 |
| 73 | 69001.* | Auxiliary Venturi, Primary | 1 |
| 73a | 69001.* | Auxiliary Venturi, Secondary | 1 |
| 74 | 77502.* | Air Corrector Jet Primary | 1 |
| 74a | 77502.* | Air Corrector Jet Secondary | 1 |
| 75 | 61455.* | Emulsion Tube, Primary | 1 |
| 75a | 61455.* | Emulsion Tube, Secondary | 1 |
