34 ICH Exploded View
| No | Part No | Description | Qty |
|---|---|---|---|
| 1 | 31706.080 | Carburetor Body | 1 |
| 2 | 37022.010 | Fuel Filter Screen | 1 |
| 3 | 52000.010 | Float Pin | 1 |
| 4 | 61002.018 | Strainer Inspection Plug | 1 |
| 5 | 83102.070 | Needle Valve Gasket | 1 |
| 6 | 77201.* | Air Corrector Jet | 1 |
| 7 | 76407.* | Pump Jet | 1 |
| 8 | 61440.* | Emulsion Tube | 1 |
| 9 | 79507.* | Needle & Seat | 1 |
| 10 | 73801.* | Main Jet | 1 |
| 11 | 79701.* | Pump Valve | 1 |
| 12 | 41575.010 | Bushing | 2 |
| 13 | 41015.019 | Float | 1 |
| 14 | 10015.494 | Throttle Shaft | 1 |
| 15 | 61280.020 | Pump Control Rod | 1 |
| 16 | 64520.023 | Throttle Plate Fixing Screw | 2 |
| 17 | 47407.261 | Accelerator Pump Diaphragm | 1 |
| 18 | 64005.007 | Throttle Plate | 1 |
| 19 | Not Available | Pump Cover | 1 |
| 20 | 64565.001 | Screw | 4 |
| 21 | 47600.107 | Accelerator Pump Spring | 1 |
| 22 | Not Available | Plug | 1 |
| 23 | 64625.012 | Throttle Stop Screw | 1 |
| 24 | 32610.005 | Split Pin | 2 |
| 25a | 52570.009 | Idle Jet Holder | 1 |
| 25b | 43904.050 | Idle Cut Off Solenoid | 1 |
| 26 | 74409.* | Idle Jet | 1 |
| 27 | 41565.019 | O Ring For Idle Jet | 1 |
| 28 | 47600.007 | Spring For Throttle Stop Screw | 1 |
| 29 | Not Available | Carburetor Body | 1 |
| 30 | Not Available | Bushing | 1 |
| 31 | 47600.007 | Spring For Adjusting Screw | 1 |
| 32 | 64750.048 | Carb Adjusting Screw | 1 |
| 33 | Not Available | Plug | 1 |
| 34 | 45136.029 | Throttle Valve Control Lever | 1 |
| 35 | 34715.014 | Throttle Shaft Fixing Nut | 1 |
| 36 | 55520.002 | Shaft Lock Tab | 1 |
| 37 | 45032.075 | Fast Idle Control Lever | 1 |
| 38 | 55530.002 | Wavy Washer | 1 |
| 39 | 12775.007 | Bushing | 1 |
| 40 | Not Available | Lever | 1 |
| 41 | 47610.058 | Spring For Choke Lever | 1 |
| 42 | 55555.016 | Shaft Spacer | 1 |
| 43 | 41565.001 | O-Ring | 1 |
| 44 | 70519.450 | Auxiliary Venturi | 1 |
| 45 | 41700.010 | Top Cover Gasket | 1 |
| 46 | 58702.023 | Choke Cable Bracket | 1 |
| 47 | 61280.021 | Fast Idle Control Rod | 1 |
| 48 | 64700.012 | Lever Fixing Screw | 1 |
| 49 | 47610.003 | Spring | 1 |
| 50 | 55510.002 | Washer | 1 |
| 51 | 64700.012 | Lever Fixing Screw | 1 |
| 52 | 45202.125 | Lever | 1 |
| 53 | 64615.004 | Screw | 1 |
| 54 | 47605.040 | Spring | 1 |
| 55 | 10015.279 | Choke Shaft | 1 |
| 56 | 64525.003 | Choke Plate Fixing Screw | 2 |
| 57 | 64010.026 | Choke Plate | 1 |
| 58 | 10304.022 | Rubber Air Filter Adaptor | 1 |
| 59 | 47407.250 | Power Valve Diaphragm | 1 |
| 60 | Not Available | Screw | 3 |
| 61 | Not Available | Power Valve Cover | 1 |
| 62 | 47600.131 | Spring | 1 |
| 63 | 64700.005 | Top Cover Fixing Screw | 4 |
